Model:
STD12V 100AHBattery Energy Capacity:
1200WhRated Voltage:
12VRated Cell Capacity:
100AhWeight:
29KgCycle Times:
800 TimesCertification:
CE MSDS UN38.3
12V 100AH Lithium Batteries
Easy access for faster installation and maintainence.
Optimal energy density, save floor space.
No leakage and no acid smog spray during the operation.
| Nominal Voltage | 12V |
| Capacity | [email protected]@25°C(77°F) |
| Weight | 29.0kg |
| Length | 407mm |
| Dimensions Width | 174mm |
| Height | 235mm |
| Internal Resistance (full charged) | 5.7m2 |
| Short- circuit Current | 1755 A |
| Self Discharge @25°C(77°F) | Less than 4% after 30 days storage |
| Operating Temperature Range |
Discharge:-40°C ~50°C(-40°F~122°F) Charge:-20°C ~45°C(-4°F ~113°F) Storage:-20°C ~ 40°C(-4F ~104"F) |
| Recommended Operating Temperature | 15°C~25°C(59°F~77°F) |
| Recommended Charging Current | 20 A |
| Charging Voltage @25C(77°F) |
Float: 2.23 V/cell Equalize: 2.35 V/cell |
| Terminal |
M8 |
| Container Materials |
ABS/ABS V0(Optional) |
| Capacity Affected by Temperature(C1o) |
ABS/ABS V0(Optional) |
| Design Life @25°C(77°F) |
12 years |
