Model:
Growatt MAX 50KTL3 LVOutput Voltage:
220V/380V,230V/400V(340-440V)Max Output power:
55500VAPV Input Voltage:
1100VWeight:
82kgDimension:
860x600x300mm(L/W/H)Display:
OLED+LED/WIFI+APPCertification:
CE,VDE0126,Greece,EN50438,EN50549,C10/C11,UTE C 15-712,IEC62116,IEC61727,IEC61683,CEI0-21,CEI0-16,N4105,BDEW,DRRG,TOR Erzeuger,G98/G99,G100,AS/NZS3100,AS4777,UNE217001,UNE206007,PO12.2,NRS097-2-1,MEA,PEA,KSC8565Warranty:
5 Years
2024 New Hot Sale Growatt 98.8% Max Efficiency 50KW On Grid Inverter
| Model Type | MAX 50KTL3 LV |
| Input Data(DC) | |
| Max.recommended PV power(for modules STC) | 75000W |
| Max.DC voltage | 1100V |
| Start voltage | 250V |
| Nominal voltage | 585V |
| MPP voltage range | 200V-1000V |
| No.of MPP trackers | 6 |
| No.of PV string per MPP tracker | 2 |
| Max.input current per MPP tracker | 26A |
| Max.short-circuit current per MPP tracker | 32A |
| Output Data(AC) | |
| AC nominal power | 50000W |
| Max.AC apparent power | 55500VA |
| Nominal AC voltage range | 220V/380V,230V/400V(340-440V) |
| AC grid frequency range | 50/60Hz(45-55Hz/55-65Hz) |
| Max.output current | 80.5A |
| Adjustable power factor | 0.8 leading…0.8 lagging |
| THDi | ﹤3% |
| AC grid connection type | 3W+N+PE |
| Efficiency | |
| Max.efficiency | 98.8% |
| European efficiency | 98.4% |
| MPPT efficiency | 99.9% |
| Protection Devices | |
| DC reverse polarity protection | yes |
| DC switch | yes |
| AC/DC surge protection | Type II/Type II |
| Insulation resistance monitoring | yes |
| AC short-circuit protection | yes |
| Ground fault monitoring | yes |
| Grid monitoring | yes |
| Anti-islanding protection | yes |
| Residual-current monitoring unit | yes |
| AFCI protection | Optional |
| Anti-PID function | Optional |
| General Data | |
| Dimensions(W/H/D) | 860x600x300mm |
| Weight | 82kg |
| Operating temperature range | -25℃-+60℃ |
| Self-Consumption (night) | ﹤1W |
| Topology | Transformerless |
| Cooling | Smart air cooling |
| Protection degree | IP 65 |
| Relative humidity | 0-100% |
| Altitude | 4000m |
| DC connection | H4/MC4 (Optional) |
| AC connection | Cable gland+OT terminal |
| Display | OLED+LED/WIFI+APP |
| Interfaces:RS485/USB/WIFI/GPRS/RF | Yes/Yes/Optional/Optional/Optional |
| Warranty:5 years/10 years | Yes/Optional |
| CE,VDE0126,Greece,EN50438,EN50549,C10/C11,UTE C 15-712,IEC62116,IEC61727,IEC61683,CEI0-21,CEI0-16,N4105,BDEW,DRRG,TOR Erzeuger,G98/G99,G100,AS/NZS3100,AS4777,UNE217001,UNE206007,PO12.2,NRS097-2-1,MEA,PEA,KSC8565 | |
| Growatt MAX 50 KTL3 LV is a three phase solar inverter designed for residential and commercial use. As an inverter, its primary function is to convert the direct current (DC) electricity produced by solar panels into alternating current (AC) electricity that can be used to power homes and businesses. One of the main features of the Growatt MAX is its high efficiency, which allows it to maximize the power output of solar panels, even under challenging environmental conditions such as shading, dust or extreme temperature. The inverter is equipped with MPPT (maximum power point tracking) technology, which continuously monitors and adjusts the electrical load to optimize the amount of energy that can be produced by the solar panels. |
